Image Description and Details :

Some time ago I posted a photo with the Astrobin comment ( http://www.astrobin.com/57641/ ) that I suspected that the alignment of craters near Muller could be a Catena.Seeing this new photo taken a few days ago when the two are present (Muller and Davy) this feeling gets even stronger.Still, I reserve the right to doubt mainly due to the diameter of the craters that appear to form Muller, they are too large for us to imagine a stone block of this size rebounding or even a succession of blocks hitting the Moon after the initial object has been fragmented. .However, not being totally impossible, the suggestion for posteriority remains.Catena, catenae (Chain of Craters) -Name adopted by the UAI to designate a chain of craters on the surface of the moon or a planet. They are the result of the rebound and eject material from the impact that formed the main crater. Davy crater crater is one of the most spectacular crater ridges on the Moon, stretching about 50 km away from the rim of ancient Davy crater.

Copyright: Astroavani

Image Description and Details : With only 2 months left to complete 10 years of the ghost crater discovered by me, I present a new photo in better resulution of the formation in question and take the opportunity to transcribe the original text with some minor adaptations."I've always had the greatest interest in astrophotography of Lunar formations and from the beginning, using mainly the Virtual Moon Atlas, I tried to find and know the most striking features of the regions I observed or photographed.As time went by, I acquired a better knowledge and more easily recognized these regions and their main accidents, which greatly facilitated the perception of anything that clashed with the traditionally observed landscape.So on January 5, 2012, photographing the region near Plateau Aristarchus, I noticed a strange depression that caught my attention. I tried to locate it on lunar maps and even in the Virtual Moon Atlas, but I found nothing.I searched the internet, asked for help from colleagues in Brazil and abroad to clarify what this training could be, I believed that it should already be known or that others had already observed it.In principle, I couldn't find any reference to this lunar formation.Looking at the attached photo, the impression we have is the existence of a depression that is only revealed when the Sun is at a very low angle of illumination.I sent the original photos to my friend Vaz Tolentino from the Lunar Observatory (VTOL) back in 2012 and he gave me the following explanation: Indeed, your photo, due to the angle of sunlight, captured an interesting and unusual circular depression, which has along its southwestern rim, the crater WOLLASTON D (5km in diameter). The formation is very strange in that it doesn't look in the style of known ghost craters. The strange and unusual thing is that, it appears that the supposed crater was flooded by basaltic lava and, instead of filling up and leveling off with the surrounding outer floor, it only filled a little and didn't even out, remaining like a "gourd" or "bowl ", in addition to leaving no traces of a central peak. This depression appears to be about 42 km in diameter, being slightly larger than ARISTARCHUS. I checked LRO images and unfortunately I can't identify anything due to the sunlight being high in the photos. We need more photos of this region, in light conditions similar to the one in this photo.At Alexandre Amorim's suggestion, I decided to contact BAA (http://www.baalunarsection.org.uk/) Lunar Section where I made contact with Dr. Anthony Cook. I sent to the same the photos obtained by me in January and June 2012, as well as I reported the suspicion that the referred depression had not yet been catalogued. After exchanging several emails, I received the following message from Dr. Cook, which I transfer in full:On Mon 4/06/12 07:06 , "Tony Cook [atc]" atc@aber.ac.uk sat:Dear Avani,Thank you for your images. It looks like a buried ghost crater that you have found. Please keep on looking for another ghost craters elsewhere on the Moon because I think that there may be quite a few that are visible near to sun rise or sunset that remain to be discovered. I think this work will be of great interest to Peter the Greek.

Dr Anthony Cook Institute of Mathematics and Physics, Aberystwyth University, Penglais, Aberystwyth, Ceredigion. SY23 3BZ. United KingdomIn April 2013 using the new QHY 5L camera, a color CMOs dedicated to high resolution Lunar and planetary photography, I got a more detailed photo of the place where the depression was located:This allowed colleague Vaz Tolentino to trace the altimetric profile of depression and perform the following analysis:"Dear Avani and Amorim:Analyzing the Avani photos (January/2012 - April/2013), together with the altimetric profile that presents a classic phantom crater depression, I reach the conclusion that, most likely, it is the discovery of a new phantom crater without cataloging.Also analyzing the altimetry of the ghost craters DAGUERRE, LAMONT and that discovered by VTOL in February 2011, I came to the conclusion that they have very similar altimetric profiles, and the Avani ghost crater is a little shallower (46 km of diameter per 130 m depth) than DAGUERRE and LAMONT (both approximately 400 m deep).However, Avani's ghost crater depth (130m) is more compatible with the ghost crater discovered by VTOL (which is approximately 100m deep). What this means?It means that, in the past (at the time of the ancient selenographers), when the main interest in observing the Moon was to map its relief, identifying and naming its formations, they did not have the current technology, that is, shallow formations like these two Phantom craters (Avani and VTOL) are very difficult to see through an eyepiece, to be sure of what you are actually looking at.After the initial period of cataloging and naming relief formations, lunar map drawings and other studies, the space age arrived. The first robotic lunar probes (Soviet and American) and the manned landings of the APOLLO missions had other scientific goals than discovering new, uncatalogued formations. Furthermore, even in the very high resolution photos taken by modern robotic lunar probes (SELENE, LRO, GRAIL, etc.), the images were mostly captured with sunlight coming from above and not obliquely, which makes it difficult relief enhancement and does not facilitate the identification of shallower formations such as these phantom craters.For modern selenographs, only after the technological evolution of digital cameras (CCD and CMOS), together with the evolution of telescope optics (large and good mirrors and also APO lenses), combined with the favorable angle of incidence of light on the lunar surface, it became easier to identify new smaller formations, "camouflaged" and not cataloged on the Moon.Congratulations Avani Soares on your discovery!Another point marked by the new generation of Brazilian selenographers. A hug from the VTOL team!In this way, I believe that any misunderstanding regarding the existence and identification of the aforementioned training is ruled out, only lacking the official disclosure and recognition to crown the aforementioned work."

Copyright: Astroavani

Image Description and Details :

Rupes Recta is a linear fault on the Moon, in the southeastern part of the Mare Nubium. The name is Latin for straight cliff, although it is more commonly called the Straight Wall. This is the most well-known escarpment on the Moon, and is a popular target for amateur astronomers.

When the sun illuminates the feature at an oblique angle at about day 8 of the Moon's orbit, the Rupes Recta casts a wide shadow that gives it the appearance of a steep cliff. The fault has a length of 110 km, a typical width of 2–3 km, and a height of 240–300 m. Thus although it appears to be a vertical cliff in the lunar surface, in actuality the grade of the slope is relatively shallow.

To the west of this escarpment is the crater Birt, which is about 17 km in diameter. The Birt Rille is a slightly curved ~50 km long channel that starts and ends in a pit.

Telescope: Clestron 9.25 f/10

Reducer/corrector: No reducer

Filter: Baader UV-IR cut

Mount: Orion Atlas EQG

Camera: DMK 23U618

Exposure: 2000 frames @ 60fps x 2 images mosaic

Procesing: Autostakkert + Registax + PixInsight

Copyright: Astronomica.es - Jaime Fernández

Image Description and Details :

Sinus Imbrium to PlatoSinus Iridum (“Bay of Rainbows”) to crater Plato on the northwestern rim of Mare Imbrium. Out in the lava sea, Montes Recti (“Straight Range”) points toward Montes Teneriffe just below Plato (“Tenerife Mountains”, as in the Canary Islands. These isolated mountains form part of an inner impact uplift rim of Imbrium, gouged by an asteroid estimated at 236 km across.Santel MK-91 230 mm f/13 Maksutov-Cassegrain (FL 3,000 mm) on an AP 900 mount, from January 25, 2021. Camera: FLIR Grasshopper 2 GigE; Best 1,600 of 13,200 frames at 22 FPS, from Ossipee, New Hampshire.

Copyright: Robert Gillette

Pythagoras Crater is at the center of this field of view and is a prominent impact crater located near the northwestern limb of the Moon. It has a diameter of 80 miles and is 16,400 feet deep. The prominent central peak rises just over 4,200 feet and is casting a very long shadow that appears to just be touching the western wall of the crater. The rim is well-preserved and the terraced walls are quite apparent. Captured Jan 26 during a full terminator imaging session at 20:28 during the 97.3 % waxing phase. To the southeast is Babbage and to the northeast is Anaximander.Celestron CPC Deluxe 1100 HDAltair IMX174 MonoZWO Filter Wheel - Green Channel FilterX-Cel 3.0 BarlowPrimalucelab Eagle 2 Pro

Copyright: Gary Varney

Many interesting the crater Hayn located to the northeast limb of the Moon. The observation of the crater is affected by the libration phase and this limits its view.

C14 Edge HD, Fornax52 mount, ASI174 mono, Baader R+IR>610nn Barlow Zeiss.

https://www.astrobin.com/full/ue0hip/0/?nc=user

Agerola-Amalfitan-Coast-Italy

Copyright: Morrone Luigi
